Megawave R290 (2.92–9.1 kW)

Specifications and technical data

Air Source (ASHP)DomesticR2902.92–9.1 kW

Manufacturer	Megawave
Model	R290
Model code	MWMHPC-6KW1
Heat pump type	Air Source (ASHP)
Application	Domestic
Refrigerant	R290
Mode	Heating & cooling
Heating capacity	2.92–9.1 kW
Max heating output (low temp)	8.16 kW at A7/W55
COP (heating)	4.77 at A7/W35
Operating range (air)	-25 to 45 °C
Heating flow temperature	up to 75 °C
Power input	3 kW
Electrical supply	220-240V (Single Phase)
Cooling capacity	1.38–5.7 kW
Max cooling output (high temp)	5.7 kW at A35/W7
Cooling flow temperature	from 7 °C
Dimensions (H×W×D)	805 × 1187 × 418 mm
Operational Weight	110 kg
Data added	2026-08-30
Data source	Manufacturer datasheet
MCS certification	✓ MCS listed — eligible for Boiler Upgrade Scheme (MCS-certified install required)
MCS certificate no.	MCS HP0341/09

View manufacturer page →

Megawave MWMHPC-6KW1 R290 monobloc air-to-water heat pump, 6 kW nominal. 2.92-9.1 kW at A7/W35 with a published COP of 4.31-5.66 and ErP class A+++. Flow temperature to 75 C, operates from -25 C ambient. Highly DC inverter EVI rotary compressor, single-phase, built-in inverter circulation pump, Wi-Fi and IoT remote monitoring. MCS certified and BUS eligible.
