Immergas MAGIS PRO 4 V2
Specifications and technical data
Air Source (ASHP)ResidentialR324.4 kW
| Manufacturer | Immergas |
|---|---|
| Model | MAGIS PRO 4 V2 |
| Model code | MAGIS PRO 4 V2 |
| Heat pump type | Air Source (ASHP) |
| Application | Residential |
| Refrigerant | R32 |
| Mode | Heating & cooling |
| Heating capacity | 4.4 kW |
| Max heating output (low temp) | 3.9 kW at A7/W55 |
| COP (heating) | 5.2 at A7/W35 |
| Operating range (air) | -25 to 35 °C |
| Heating flow temperature | 20–65 °C |
| Power input | 2.1 kW |
| Electrical supply | 220-240V (Single Phase) |
| Cooling capacity | 5 kW |
| Max cooling output (high temp) | 3.6 kW at A35/W7 |
| Cooling flow temperature | 5–25 °C |
| EER (cooling) | 3.24 at A35/W7 |
| Dimensions (H×W×D) | 638 × 934 × 361 mm |
| Operational Weight | 58 kg |
| Sound power level | 58 dB(A) (Sound Power LW(A)) |
| Data added | 2026-08-30 |
| Data source | Manufacturer datasheet |
Immergas MAGIS PRO 4 V2 air-to-water heat pump, R32 split system with a wall-hung hydronic module. 4.4 kW at A7/W35 with a COP of 5.2. Single-phase. Flow temperature 20-65 C, operates to -25 C ambient.
✓ Manually verified by Heat Pump Database
✎ Suggest a correction to this data
Data is compiled from manufacturer sources and may contain errors or gaps. Always confirm specifications with the manufacturer before making decisions.
