TCL R290 Heat Pump (4.4 kW)
Specifications and technical data
Air Source (ASHP)ResidentialR2904.4 kW
| Manufacturer | TCL |
|---|---|
| Model | R290 Heat Pump |
| Model code | THMLd-4D/3FBp-A |
| Heat pump type | Air Source (ASHP) All Air Source heat pumps → |
| Application | Residential All Residential heat pumps → |
| Refrigerant | R290 All R290 heat pumps → |
| Mode | Heating & cooling |
| Heating capacity | 4.4 kW |
| Max heating output (low temp) | 4.4 kW at A7/W55 |
| COP (heating) | 5.1 at A7/W35 |
| SCOP (heating) | 4.95 at W35 |
| Operating range (air) | -25 to 35 °C |
| Heating flow temperature | 25–80 °C |
| Electrical supply | 220-240V (Single Phase) |
| Cooling capacity | 4.5 kW |
| Max cooling output (high temp) | 4.5 kW at A35/W7 |
| Cooling flow temperature | 5–20 °C |
| EER (cooling) | 2.8 at A35/W7 |
| Dimensions (H×W×D) | 704 × 1220 × 390 mm |
| Operational Weight | 75 kg |
| Sound power level | 57 dB(A) (Sound Power LW(A)) |
| Data added | 2026-10-21 |
| Data source | TCL Tri-thermal ATW heat pump brochure |
| Verification | Verified by a human |
Check noise at a neighbour’s window (MCS 020 a) →
TCL THMLd-4D/3FBp-A Tri-thermal R290 air-to-water monobloc heat pump, 4.2 kW at A7/W35, flow up to 80 °C, heating, cooling and DHW, single-phase.
✎ Suggest a correction to this data
Data is compiled from manufacturer sources and may contain errors or gaps. Always confirm specifications with the manufacturer before making decisions.
